Wall mounted AIO built in IR touch screen--silver

Features：

1.Size: 43inch --65 inch
2.System:Android/Window optional
3.Application: Indoor
4.Interface:USB,HDMI,WIFI,BLUETOOTH,RJ45,TF,etc.
5.Brightness: 350cd/m², 500cd/m² or 700cd/m²
6.Touch: IR touch screen

Description

1 .1 Basic specifications
Resolution		1920×1080 or 3840×2160
Color	Standard color	16.7M
Color	Maximum color	Full Color
LCD panel-screen	Type	LED
	Response time	8ms
	Brightness	350cd/m², 500cd/m² or 700cd/m²
	Contrast	1200:01:00
	Viewing angle	178°
	Color	16.7M
	Aspect Ratio	16:09
Power		AC100～240V,50/60Hz
Maximum current		≤1.5A
Working environment	Temperature	-10℃～50℃
	Relative humidity	10％～90％
	Altitude	≤5000 M
Storage environment	Temperature	-20℃～60℃
Storage environment	Relative humidity	10％～90％
Service life		≥30000 Hrs
Installation method		Wall mount
Operation method		Smart touch
Case material		Profile+metal

1.2 Touch function technical parameters
Touch indicator	Touch form	Infrared ten-point touch technology
	resolution	32768(W) × 32768(D)
	Touch method	Finger or pen
	positioning accuracy	2mm
	Touch accuracy	<1.5mm（Central region），<2.5mm（Marginal area）
	Glass	Yes
	Minimum diameter of touch object	≥ 5mm
	Number of touches	Unlimited
	Interface	USB2.0 full speed

1.3 Options of Windows system configuration
	CPU	INTER I3/ (I5/I7optional)
Configuration of PC （Optional）	Ram	Kingston/4GB/8GB/DDR3/1600MHZ
	hard disk	SSD128G/256GB/ (optional HDD500GB/1GB)
	Types of Hard disk	Solid state drive (optional mechanical hard drive)
	Operating system	Windows 7/10 trial version (professional system is optional)

1.4 Options of Windows system configuration
Android parameters：RK3288
CPU	RK3288 Cortex-A17 Quad core, 2.0 GHZ
	ARM Mali-T764 GPU
RAM	2G（optional 4G）
Storage	NAND FLASH/EMMC 8GB（optional 16G）
System	Android 5.1/7.1
Decoding resolution	Support highest 1080P
Network support	Ethernet, WiFi, 3G/4G (optional)
Video support	Support AVI (H.264, DIVX, DIVX, XVID), rm, rmvb, MKV (H.264, DIVX, DIVX, XVID), WMV, MOV, MP4 (.H.264, MPEG, DIVX, XVID), DAT (VCD format), VOB (DVD format), PMP, MPEG, .MPG, FLV (H.263, H.264), ASF, TS, TP, 3GP, MPG and more than 30 formats
Image Format	Support BMP, JPEG, PNG, GIF
USB2.0 interface	2 USB HOST standard interfaces, 2 USB expansion interfaces
RTC Real Time Clock	Support
Timer switch	Support multiple modes of timing switch
System Upgrade	Support USB upgrade, SD card upgrade, remote upgrade
Support information publish system	LAN/Cloud platform (optional)

Android parameters：RK3399
CPU	RK3399 eight-core, main frequency 2.0 GHz
	Dual-core Cortex-A72 up to 2.0GHz
	Quad-core Cortex-A53 up to 1.5GH
	Mali-T864 GPU
RAM	2G（optional 4G）
Storage	NAND FLASH/EMMC 16GB( optional 32G）
System	Android 7.1/8.0
Decoding resolution	Support highest 1080P
Network support	Ethernet, WiFi, 3G/4G (optional)
Video support	Support AVI (H.264, DIVX, DIVX, XVID), rm, rmvb, MKV (H.264, DIVX, DIVX, XVID), WMV, MOV, MP4 (.H.264, MPEG, DIVX, XVID), DAT (VCD format), VOB (DVD format), PMP, MPEG, .MPG, FLV (H.263, H.264), ASF, TS, TP, 3GP, MPG and more than 30 formats
Image Format	Support BMP、JPEG、PNG、GIF
USB2.0 interface	2 USB HOST standard interfaces, 2 USB expansion interfaces
RTC Real Time Clock	Support
Timer switch	Support multiple modes of timing switch
System Upgrade	Support USB upgrade, SD card upgrade, remote upgrade
Support information publish system	LAN/Cloud platform (optional)
