Interactive Touch Table

Features：

Customized Shape for your choice ！

Good looking and full of science fiction ！

Move freely ！

Long service life ！

Applications are diversified ！

Waterproof, vandal proof , weatherproof ！

Description

LCD Screen: Samsung,LG,AUO,Chimei Full New Grade TFT LCD screen ,LED Backlight

Resolution:1920*1080

Brightness : 360cd/m2,700cd/m2

Material : Metal Case;Aluminum Alloy Profile+Metal Case

Tempered Glass:3mm,4mm,5mm

Functions: 3D interactive display of video, pictures, and other media content

Display color: 16,7M

Touch type: infrared or capacitive touch

Touch accuracy: no drift, deviation within 1 mm to 3 mm.

Operating temperature:-10, c, ~,+60, c

Response work: 18 to 50 milliseconds

Touch software: SWPF 3D interactive software platform or finger and touch pen interaction

Audio: 2×,5W Horn

Application scenario: Exhibition, 4S store, leisure and entertainment, Business/ office room, upscale club, Coffee shop, Family reception room

Available Size:43/49/55inch

Size	Resolution	Brightness （cd/m2）	Contrast	Active area(mm)	Viewing angle	Proportion
43	1920*1080	360	2000:1	941*530	178	16:9
49	1920*1080	360	2000:1	1074*604	178	16:9
55	1920*1080	360	3000:1	1214*680	178	16:9

Available Touch Screen ：

IR Touch Screen (Free Driver)

Capacitive Touch Screen (Free Driver)

Feature: USB Interface, Plug & Play,
Resolution: 32768*32768

Response Time: 8MS-15MS

Input Method: Finger or other Opacity Touch Medium
Compatible OS: WindowsXP, 7, 8, 10, Linux,Mac, Android
Work Voltage: DC 5V(+4.75_+5.25V)

Feature: USB Interface, Plug & Play, Tempered Glass 3mm

Input Method:Finger ,Capacitive Touch Pen
Transparency: ≥85%±5%

Compatible OS: WindowsXP, 7, 8, 10, Linux,Mac, Android

Connection Cable: FPC

Active Force: ≤10g

Structure: Glass+Glass

Available Android / Windows System:

Android System

Computer System

RK3188/A83T/RK3288/RK3399

System: Android 4.4/5.1/6.0/7.1 (optional)

Storage: 8G/16G/32G/64G (optional)

Memory: DDR3 2G/4G

Storage extension: Up to 32GB SD card/TFC card expansion, SATA driver extension is also supported

WIFI:802.11b/g/n

Interface: USB * 2/DC12V/HDMI/RJ54

Integrated CPU Intel: I3/I5/I7

Memory: DDRIII/4/8/16GB

Network card: RTL8100E

Wifi:802.11 B/G/N

Hard disk: HDD:500GB/1TB

SSD:120/128/240/256/512GB

Integration: Intel HD Graphics 4400

Speaker: 2 built-in high-quality stereo speakers (3w or 5w)

Interface: USB * 4/VGA/HDMI/LAN

Discrete CPU Intel :I3/I5/I7

Motherboard: H81/H110
