Wall Mounted Advertising Player

Home-Products-Wall Mounted Advertising Player
Others-Big Sizes
<
>
  • Others-Big Sizes
  • Others-Big Sizes
  • Others-Big Sizes

Others-Big Sizes

Features:

1. Support USB Disc update automatically !

2. Remote Controller;Optional Touch screen Control (Dual ,Multi Touch) !

3. SupportSD/MMC card &USB storage !

4. Support OSD menu&file rotation function !

5. Support rolling title !

6. Support Multi OSD languages !

7. Support Multi Display Zones on Screen !

8. Support clock&timing play function !



Description

LCD Screen: Samsung,LG,AUO,Chimei Full New Grade TFT LCD screen ,LED Backlight

Resolution:1080*1920

Brightness : 360cd/m2,700cd/m2

Material : Metal Case;Aluminum Alloy Profile+Metal Case

Tempered Glass:3mm,4mm,5mm

Speakers2*5w(5w to 55’’&above)Amplified Speakers

Touch Screen :(10,16,32 is optional) Capacitive  / IR Touch Screen (optional)

Video InterfaceVGA,DVI,HDMI

Audio:3.5mm Audio Jack

Compatible OS:Windows 7,8,10,Android

Optional functionHD Web Camera;Blue Tooth  ; 4G



Application Area: Hotel&Inn,Commercial Building&Office,Exhibition&Fair,Recreation&Relax,Traffic Center&Train Station,Airport,Bus&Taxi,Shopping Mall&Stores.



Available Size:65/75/86inch

Size

Resolution

Brightness

cd/m2

Contrast

Active area(mm)

Viewing angle

Proportion

65

1920*1080

360

4000:1

1435*808

178

16:9

75

3840*2160

360

4000:1

1653.6*932

178

16:9

86

3840*2160

360

4000:1

1877*1059

178

16:9



Available Touch Screen :

IR Touch Screen  (Free Driver)

Capacitive Touch Screen  (Free Driver)

Feature: USB Interface, Plug & Play,
Resolution: 32768*32768

Response Time: 8MS-15MS

Input Method: Finger or other Opacity Touch Medium
Compatible OS: WindowsXP, 7, 8, 10, Linux,Mac, Android
Work Voltage: DC 5V(+4.75_+5.25V)

Feature: USB Interface, Plug & Play, Tempered Glass 3mm

Input Method:Finger ,Capacitive Touch Pen
Transparency: ≥85%±5%

Compatible OS: WindowsXP, 7, 8, 10, Linux,Mac, Android

Connection Cable: FPC

Active Force: ≤10g

Structure: Glass+Glass



Available Android /Windows System:

Android System

Computer System

RK3188/A83T/RK3288/RK3399

System: Android 4.4/5.1/6.0/7.1 (optional)

Storage: 8G/16G/32G/64G (optional)

Memory: DDR3 2G/4G

Storage extension: Up to 32GB SD card/TFC card expansion, SATA driver extension is also supported

WIFI:802.11b/g/n

 Interface: USB * 2/DC12V/HDMI/RJ54

Integrated CPU Intel: I3/I5/I7

Memory: DDRIII/4/8/16GB

Network card: RTL8100E

Wifi:802.11 B/G/N

Hard disk: HDD:500GB/1TB

SSD:120/128/240/256/512GB

Integration: Intel HD Graphics 4400

Speaker: 2 built-in high-quality stereo speakers (3w or 5w)

Interface: USB * 4/VGA/HDMI/LAN

Discrete CPU Intel :I3/I5/I7

Motherboard: H81/H110

Memory: DDRIII/4/8/16GB

Network card: RTL8100E

Wifi:802.11 B/G/N

Hard disk: HDD:500GB/1TB

SSD:120/128/240/256/512GB

Integration: Intel HD Graphics 4400

Discrete graphics card: 2G/4G/6G (optional)

Speaker: 2 built-in high-quality stereo speakers (3w or 5w)

Interface: USB * 4/VGA/HDMI/LAN
